Midas PRO2 User Manual

Solo, mute and fader 263
PRO2 Live Audio System
Owner’s Manual
Solo, mute and fader
Each input fast strip contains the MUTE and SOLO buttons motorised fader. The fader
is replicated in each input fast strip on the GUI and also in the masters detail area (GUI
channel strip). The fader controls the channel signal level and provides instant
feedback of level settings.
Item Description
1 LCD select button.
2 MUTE button, mutes all post-processing signals exiting the channel. In
addition to scene recall, it can also be remotely muted from the auto-mute
masters.
3 SOLO button, activates signal routing to the monitor A or B section of the
control centre (depending on the status of the solo B button) by sending
the input channel signal to PFL mono and AFL stereo buses. The solo
system is auto-cancelling, so that each new solo cancels the last one. Input
solos override any active VCA and bus solos.
This button is a latching type. Give a short press to latch it and a long
press to self-cancel when it is released.
4 Solo B button (GUI only), changes the operation of the SOLO switch so that
it routes signals to the monitor B section of the control centre.
5 Motorised fader.
1
2
3
5
2
4
3
5

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
