306 Appendix C: Technical Specification
PRO2 Live Audio System
Owner’s Manual
PRO2 general specifications
* Weights are approximate and out of flight case.
Mixing control assistance 6 x auto-mutes
6 x surface POPulation groups
8 x VCA faders
8 x VCA associated POPulation groups
176 x MCA faders
176 x flipped MCA POPulation groups
1000-scene snapshot automation
Resilience N+1 cable redundancy and dual redundant
PSUs
Sampling frequency 96kHz
Latency delay <2ms input to master (no compensation)
Dynamic range 106dB, 22Hz to 22kHz (no pre-emphasis)
Maximum voltage gain 80dB inputs to subgroups and masters
86dB inputs to aux and matrix
Crosstalk at 1kHz -100dB physically adjacent input channels
Crosstalk at 10kHz -90dB physically adjacent input channels
Fader/pan cut off at 1kHz -100dB
Fader/pan cut off at 10kHz -100dB
Display screens 1 x 15” daylight-viewable colour screen
LCD switch 25 x RGB colour
Motorised faders 20 x touch-sensitive
Fader resolution 1024 steps
Encoders 31 x touch-sensitive
Encoder resolution 512 steps
Dimensions PRO2 control centre: 1179.6 mm wide x
730.3 mm deep (46.44” x 27.75”)
PRO2C control centre: 882 mm wide x
730.3 mm deep (34.72” x 28.75”)
DL251 I/O box: 5U x 200 mm deep
Net weight* PRO2 control centre: 40 kg
PRO2C control centre: 37 kg
1 x DL2531: 10 kg
Power requirements 100V to 240V a.c. ±10%, 50 to 60Hz
Operating temperature range +5°C to +45°C
Storage temperature range -20°C to +60°C
