Midas PRO2 User Manual

76 Chapter 9: Basic Operation
PRO2 Live Audio System
Owner’s Manual
Setting up a mix
The PRO2 has 24 configurable mix buses, each of which can be aux mixes, subgroups
or mix minus. The aux mixes can also be set up as stereo pairs (restricted to like-
coloured buses) or mono. To keep the control surface manageable, access to these
mixes is confined to the mix section in the channel detail area, which can be scrolled up
and down on a ‘virtual’ surface.
Figure 6: Mix section
On the GUI, the bank of mix buses in each input fast strip (see Figure 7 below) are
colour matched, but also show mix bus status information.
Figure 7: Typical mix section in a GUI input fast strip
Quick access button
mix section
GUI channel strip
This transition point, where solid colours
change to translucent, indicates 0dB
across the eight auxes
Bar shows that this
signal is pre-fader
Ramp shows that
this signal is post-
fader
Bright number and
coloured ramp/bar shows
that this mix bus is
currently selected; the
colour corresponds to its
associated control knob on
the control surface and
GUI detail area
Bright ramp/bar
shows that this
mix bus is on
Dimmed ramp/bar
shows that this
mix bus is off

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
