Midas PRO2 User Manual

About the GEQ window 123
PRO2 Live Audio System
Owner’s Manual
About the GEQ window
In the centre of the GUI screen, the GEQ window shows the selected GEQ’s front panel.
This gives you full control of the GEQ via the GUI controls in the navigation zone by
using the trackball and left and right buttons. Below the GEQ is an assignable
controls panel that lets you select and control the GEQ faders (singly or in groups) and
the controls on the right.
GEQ window
>> To open a GEQ unit window
In the Graphic EQs screen, click on a non-control area of the unit you want.
Item Element Description
1 COPY button Copy and paste function button (see Chapter
18 "Copy And Paste" on page 185).
2 PASTE button Copy and paste function button (see Chapter
18 "Copy And Paste" on page 185).
3 FLAT button Sets all of the GEQ’s faders to 0dB.
4 STORE PRESET
button
See Chapter 24 "User Libraries (Presets)" on
page 235.
5 LOAD PRESET
button
See Chapter 24 "User Libraries (Presets)" on
page 235.
6 CLOSE button Closes the GEQ window.
7 assignable
controls panel
See Chapter 19 "Assignable Controls (I Zone)" on
page 187.
8 GEQ panel Shows the front panel of the GEQ (see “GEQ front
panel features” on page 124.
9 Drop-down list For selecting the source of the GEQ.
1
9
23 45
8
7
6

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
