Midas PRO2 User Manual

312 Appendix C: Technical Specification
PRO2 Live Audio System
Owner’s Manual
PRO2 control surface - analogue audio system inputs
PRO2 control surface - analogue audio system outputs
PRO2 control surface - digital audio system inputs and outputs
PRO2 control surface - control data system inputs and outputs
Connector 3-pin XLR balanced
A/D converter 24-bit, 96kHz and 128 times oversampling
Talkback connector 3-pin XLR balanced line
Talk connector 3-pin XLR balanced mic with 48V phantom
voltage
Meters (11-off) 10-segment, -36dBu to +21dBu
Connector 3-pin XLR balanced
D/A converter 24-bit, 96kHz and 128 times oversampling
Monitor connector 3-pin XLR balanced line
Talk connector 3-pin XLR balanced line
Headphone connector 1/4” Jack (stereo)
Automation advance connector 1/4” Jack (mono)
Meters (24-off) 10-segment, -36dBu to +21dBu
Meters (2-off) 20-segment, -36dBu to +21dBu
Input connector AES3 (two channels of digital audio) on 3-pin
XLR
Sample rates Accepts any frequency 32kHz - 96kHz
Bypass Sample rate converter can be bypassed
Output connector AES3 (two channels of digital audio) on 3-pin
XLR
Sample rate 48k, 96k, or auto-tracking to inputs
Bypass Sample rate converter can be bypassed
Word length 16, 20 or 24-bit
System connector EtherCon® XLR

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
