Midas PRO2 User Manual

Talk mic 119
PRO2 Live Audio System
Owner’s Manual
The three control knobs are used in conjunction with mic XLRs (in the screen housing
and the rear connector panel) and the two TALK routing switches (internal and
external).
>> To select the internal talk mic
1 In the talk mic section of the master bay, press TALK (internal) to switch in the
talk mic section (see “Talk mic” on page 118).
2 In the source a or source b section of the master bay, press TALK. Your
chosen section will determine which system bus (A or B) the talk mic will be
sourced from (see “Monitor output (A and B)” on page 113 and “source (a and b)
sections” on page 114).
External talkback
The external talkback input is a mic/line input at the stage end of the system that,
when enabled in the monitor section (see “Monitor output (A and B)” on page 113), can
mix onto the local monitor outputs.
4 limiter control
knob
Gives continuous adjustment of the peak limiter value
from 0dB to +20dB.
5 mic gain control
knob
Provides continuous mic amplifier gain adjustment of
the mic connected to mix bay control surface. Range
is +15dB to +60dB and operates in conjunction with
the peak limiter.
6 Talk patching
sections.
See Table 25 “Navigating to the Patching screen” on
page 418.
Item Element Description

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
