Figure 10: Transfer characteristics

Input
Level
Output
Level
A
bove Threshold Compressio
n
( Below = off, Ratio = comp )
threshold
Input
Level
Output
Level
A
bove Threshold Expansio
n
( Below = off, Ratio = exp )
threshold
Input
Level
Output
Level
Below Threshold Compression
( Below = on, Ratio = comp )
threshold
Input
Level
Out p ut
Level
Below Threshold Expansion
( Below = on, Ratio = exp )
threshold
