Midas PRO2 User Manual

144 Chapter 17: Control Groups
PRO2 Live Audio System
Owner’s Manual
VCA groups
There are eight VCA groups, which are accessible via the mix fader LCD select buttons
when configured for VCA operation.
VCA groups on the control surface and GUI
Item Description
1 LCD select button, selects the VCA group and is also used for group
member assignment.
2 VCA group control, adds its level control on top of the local channel fader
controls of the group members.
3 SOLO button activates signal routing from all assigned channels to the
monitor A section of the control centre. It is used to monitor the VCA
master faders by creating a mix on the solo buses, which consists of all
input channels and audio mix groups that are assigned to control from
corresponding VCA masters.
6
5
4
3
2
8
9
1
3
2
4
7

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
