Midas PRO2 User Manual

Dynamics and EQ 273
PRO2 Live Audio System
Owner’s Manual
Compressor (D zone)
For the outputs, the dynamic section (D zone) only has a compressor in the output
channel signal path. As the D zone is also used for the gate on the input channels,
some controls may be redundant.
The output channel compressor has five styles — corrective, adaptive, creative, vintage
and shimmer — which are selectable via the MODE button. Each has a distinctive
appearance in the GUI channel strip. While the dynamic section is addressing the
compressor, all of its controls are enabled except the hold control knob.
For details of the compressor graph, see “About the compressor graph” on page 252.
The side chain is similar to the one used for the input channels, see “Side chain” on
page 255.
Item Description
1 ON switch, enables the compressor in the signal path. When switched off,
compressor is bypassed.
2 To aid set up, the compressor has a side chain listen that sends the side
chain onto a solo bus. This side chain listen LED indicator illuminates to
warn you that soloed material is from the side chain, and not the main
channel.
8
10
9
4
3
7
6
5
D zone
11
Shimmer
Vintage
Creative
9
10
3
5
7
6
8
Adaptive
Corrective

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
