Midas PRO2 User Manual

Dynamics and EQ 275
PRO2 Live Audio System
Owner’s Manual
Item Description
1 Up/down band navigation buttons (see “Navigating the PEQ output bands”
on page 277). Also used in conjunction with the blue adjacent LEDs to
show which band is currently selected. Illuminated up arrow means that
band 5 is selected, and illuminated down arrow means that band 2 is
selected.
2 Four blue LEDs, illuminate to show the current band selection. Used in
conjunction with the up and down buttons, they show — from the bottom
LED upwards — when band 1, 3, 4 or 6 is selected.
3 gain control knob, adjusts signal gain in the range -16dB to +16dB. On the
graph in the EQ processing area (GUI channel strip), causes the envelope to
move up/down, inverting as it passes the origin.
4 width control knob, adjusts the signal bandwidth in the range 0.1 Oct to
3.0 Oct. On the graph in the EQ processing area (GUI channel strip),
causes the base of the envelope to widen. (Not available for shelving
modes.)
5
6
2
1
1
2
3
4
E zone
2
2
8
Bands 1, 2 and 6 shelving modes
7
5
36

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
