About the updater screen 331
PRO2 Live Audio System
Owner’s Manual
Updater menu
The following table gives a description of the updater menu commands.
Device blocks
Each device block represents a possible or actual device connected in the system. The
device block number is referenced to the device’s ID. The colour of each device block
indicates the update status of the device, which is shown in the following table.
Unit Status window
You can get more detailed information
on the update progress of a device by
moving the pointer over it. A
translucent window (a typical one is
shown right) will open towards the
upper-right corner of the screen. The
window has a title bar at the top and
information below.
The colour of the window matches the
colour of its associated device block,
which gives an indication of its update
status, as described in the previous
section.
Command Function
Quit Exits the updater. After a power cycle, the control centre returns
to the operating condition it was in when the updater command
was selected from the GUI menu.
Select All Selects all Midas devices connected (and detected) in the PRO2
Live Audio System.
Remove All Deselects all Midas devices connected (and detected) in the PRO2
Live Audio System.
Update Now Starts the update procedure.
State Description
Grey background — appears during the updater’s ‘triggering upgrade
client’ procedure. If its appearance doesn’t change throughout the
update procedure, either there is no device connected in this position or
one has not been detected.
Blue background without roundel — appears after the updater’s
‘triggering upgrade client’ procedure has finished to show you that there
is a device connected in this position.
Blue background with roundel — appears after this device has been
selected for update.
Gold background with roundel — this device is currently being updated.
Green background with tick — this device has successfully been
updated.
Red background with cross — this device’s update has failed.
