Midas PRO2 User Manual

352 Appendix F: Parameters Affected By Scope
PRO2 Live Audio System
Owner’s Manual
Dynamics
Not applicable.
Insert
Not applicable.
EQ
The following diagram details the scoped parametric EQ parameters of the input
channels, and shows the EQ detail area in the GUI channel strip.
ABCDF G H
Item Parameter
1 All filters: freq, gain,
width, SHAPE
N/A Yes N/A Yes N/A N/A N/A
2 EQ in/out
N/A Yes N/A Yes N/A N/A N/A
B
F
G
H
A
C
D
1
2
2
1

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
