PRO2 Live Audio System

Owner’s Manual

FADER safe

The following diagram details the parameters of the masters protected by FADER safe,

and shows the master routing detail area in the GUI channel strip.

Item Control Parameter

1 Fader Fader level

2 bus trim control knob Bus trim level

3 delay control knob Delay time
