Midas PRO2

Input Channels 469
PRO2 Live Audio System
Owner’s Manual
Bus sends
The following diagram shows the input bus sends affected by stereo linking, and applies
to the 16 auxes and eight matrices.
Note: Only matrix sends 1 to 8 are shown above, but this is typically the same for all of
the bus sends (eight matrices and 16 auxes).
Item Control Parameter
1 ON switch Bus send on/off
2 level/pan control
knob
Bus level, or pan when bus is linked. (When
sending onto a stereo bus the send pan controls
are not linked.)
3 PRE switch Pre-fader on/off
4 level control knob Bus level
3
2
1
3
4
1
As per
bus sends
1-2 above
2
As per bus sends 1-2
above
5
6
2
1
3
1
3
