Midas PRO2

Matrix (matrix channels) 539
PRO2 Live Audio System
Owner’s Manual
Fader Sections
The following diagram shows the parameters of the master routing detail area copied
through scenes.
Item Control Parameter
1 MUTE switch Mute on/off
2 B switch Solo B in/out
3 Fader Level
4 Field Channel name
5 Field Channel colour
6 ST switch Link to stereo master fader
7 MON switch Link to mono master fader
8 bus trim control knob Bus trim level
9 delay control knob Delay time
1
3
1
3
5
4
8
9
2
7
6
1
3
2
