Midas PRO2

About the Patching screen 53
PRO2 Live Audio System
Owner’s Manual
Mon. (Monitor) tab — From
The Mon. (Monitor) tab allows routing of
the monitor outs and external talk
destination.
This tab can also be accessed via the dest
buttons on the Monitors screen.
I/O tab — To
The I/O tab in the To section contains the devices fitted in the stage racks (except the
mic splitters).
Inputs tab — To
The Inputs tab allows sources to be routed
to the input channels and returns.
This tab is also accessed from the src button
in the configuration section of the input
channels.
Mon. tab output Equivalent on the Monitors screen
Monitor Out A L monitor A output L
Monitor Out A R monitor A output R
Monitor Out B L monitor B output L
Monitor Out B R monitor B output R
Headphone Out L N/A
Headphone Out R N/A
External Talk Destination external talk output
