How to patch 67
PRO2 Live Audio System
Owner’s Manual
• The selected destination forms the start of the automatically patched range of
destinations.
• Sources and destinations are automatically patched in ascending order, the lowest
numbered source and the selected destination forming the first patch.
• Sources will only be patched up to the highest numbered destination of the current
destination type. If there are any sources left over, automatic patching pauses. You
can then patch these by selecting another destination.
>> To automatically patch a block of source channels
1 Click AUTO.
2 In the From section, select the source patch connectors (see “To select a block of
patch connectors in the From section” on page 65).
3 In the To section, choose the destination patch connector that will form the start
of the patched range. For example, input channel 3 (Mic3).
4 Click the destination patch connector.
The sources will be patch in numerical
sequence and in ascending order from
here onwards.
Clearing all current patching
The CLEAR function button clears all current patching, and must be used
with great caution. To alert you of the drastic nature of using this button, a
WARNING appears.
>> To clear all current patching
1 Click CLEAR. The WARNING
window (shown right) will
appear.
2 Heed the warning and do one
of the following:
• If you want to clear all
current patching, click OK.
• To cancel the clear
operation and close the
WARNING, click CANCEL.
