Mindray WATO EX-65 - Use a Sidestream CO2 Module; Prepare to Measure CO2

8-3
8.3 Use a Sidestream CO2 Module
NOTE
z This section is only applicable to the anesthesia machine configured with
sidestream CO2 module.
8.3.1 Prepare to Measure CO2
1. Attach the watertrap to the watertrap fixer and then connect the CO2 components as
shown below.
2. By default, the CO2 module is in measure mode. The [CO2 Startup] message appears
on the screen when the CO2 module is plugged in.
3. After start-up is finished, the message [CO2 Warmup] is displayed. The CO
2
module is
in ISO accuracy mode. If you perform CO
2
measurements during warm-up, the
measurement accuracy may be compromised.
4. After warm-up is finished, the CO
2
module enters full accuracy mode.
NOTE
z To extend the lifetime of the watertrap and CO2 module, disconnect the watertrap
and set the working mode of the module to standby when CO2 monitoring is not
required.
Watertrap
Watertrap fixer
Sampling tube
