Mindray WATO EX-65 - Circuit Adapter Diagram

13-3
1 Bellows housing 12 Expiration connector
2 Bag arm 13 Inspiration connector
3 Bag/mechanical ventilation switch 14 Water collection cup
4 APL valve 15 Locking hook
5 Inspiratory check valve 16 Drive gas connector
6 Expiratory check valve 17 Guide pin hole
7 Plug for O
2
sensor (O
2
sensor optional) 18 Locking catch retainer
8 Rotary handle 19 Pressure sampling connector(s)
9 Sodalime canister 20 APL valve gas outlet
10 Airway pressure gauge 21 Fresh gas inlet
11 Leak test plug 22 ACGO connector
13.1.2 Circuit Adapter Diagram
1 Bag/mechanical ventilation linked
switch
7
Locking catch
2 Pressure sampling connector(s) 8
ACGO connector
3
Heating module
9
Fresh gas inlet
4
Drive gas connector
10
APL valve gas outlet
5
Circuit switch
11
Circuit support guide(s)
6
Circuit adapter base
8
9
10
11
5
4
3
1
2
6
7
