Page #239 background imageLoading...
Page #239 background image
B-17
B.13 AG Module Specifications
AG Module
Type Three-slot module (BIS and O
2
modules are optional)
Standard ISO 11196
Measurement mode Sidestream
Warm-up time
ISO accuracy mode
Full accuracy mode
<45 s
<10 min
Pump rate
Pump rate:
Accuracy:
120/150/200 mL/min optional
±10 mL/min or ±10%, whichever is greater
Gas
CO2, O2 (optional), N2O, and any of the five anesthetic agents: Des, Iso,
Enf, Sev and Hal.
CO
2
0 to 30 %
O
2
(optional) 0 to 100 %
N
2
O 0 to 100 %
Des 0 to 30 %
Sev 0 to 30 %
Range
Enf, Iso, Hal 0 to 30 %
ISO accuracy mode
CO2
N2O
Other anesthetic agent
±0.3%ABS
±(8%REL+2%ABS)
8%REL
Gas Range (%REL) Accuracy (%
ABS
)
0 to 1
±0.1
1 to 5
±0.2
5 to 7
±0.3
7 to 10
±0.5
CO
2
>10 Not specified
0 to 20
±2
N
2
O
20 to 100
±3
0 to 25
±1
25 to 80
±2
O
2
80 to 100
±3
0 to 1
±0.15
Full accuracy mode
Des
1 to 5
±0.2
