8-10
8.4.2.4 Set Maximum Hold
In the CO2 parameter area, EtCO2 and FiCO2 values are refreshed in real-time. To set
EtCO2 and FiCO2:
1. Access the [Gas Module Setup >>] menu.
2. Select [Max Hold] and select:
îš‹ [Single Breath]: EtCO
2
and FiCO
2
are calculated based on each breath.
îš‹ [10 s], [20 s] and [30 s]: EtCO
2
and FiCO2 refer to the highest and the lowest CO2
values measured respectively within the configured time period (10 s, 20 s or 30 s).
8.4.2.5 Restore Defaults
Select [Defaults] from the [Gas Module Setup >>] menu. Then all the menu options except
[Working Mode] are restored to the factory default configurations.
8.4.2.6 Set CO2 Waveform
1. Select the waveform area to access the waveform setup menu.
2. Select [Waveform] and select [CO2].
3. Select [Sweep] and set waveform sweep speed to an appropriate value. The greater the
value is, the faster the waveform sweeps, the wider the waveform is.
4. Select [Scale] and toggle between:
îš‹ [40], [60] and [80] if the unit is mmHg;
îš‹ [5.0], [7.5] and [10.0] if the unit is % or kPa.
5. Select
to exit the current menu.
For details about displaying the CO2 waveform, refer to 5.3.3.2Display CO2 Waveform.
8.4.2.7 Set Automatic Standby Time
For microstream CO2 module, you can set a period of time after which the CO2 module
enters the standby mode if no patient breath is detected since the last patient breath detected.
To set the automatic standby time, access the [Gas Module Setup >>] menu and select [Auto
Standby (min)].
