13-27
13.4.3 Drain the Vaporizer
WARNING
z Do not reuse the agent drained from the vaporizer. Treat as a hazardous chemical.
13.4.3.1 Pour Fill System
1. Check that the vaporizer concentration control A is in the 0 (zero) position.
2. Unscrew the filler cap B.
3. Place a bottle marked with the drug name on the vaporizer under the drain tube in the
base of the filler block. Undo the drain screw C to allow the liquid to run into the bottle.
