9-6
When [Working Mode] is set to [Measure], the message [AG Startup] appears on the
screen. After start-up is finished, the message [AG Warmup] is displayed. The AG module is
in ISO accuracy mode .After warm-up is finished, the .AG module enters full accuracy mode.
9.5.5 Set CO2 Unit
In the [Gas Module Setup >>] menu, select [CO2 Unit] and toggle between [mmHg], [%],
and [kPa].
9.5.6 Restore Defaults
Select [Defaults] from the [Gas Module Setup] menu. Then all the options in this menu
except [Working Mode] are restored to the factory default configurations.
9.5.7 Set CO2 Waveform
1. Select the waveform area, open the corresponding menu.
2. Select [CO2] for [Waveform].
3. Select [Sweep] and set waveform sweep speed to an appropriate value. The greater the
value is set to, the faster the waveform sweeps, the wider the waveform is.
4. Select [Scale] to change the select CO
2
waveform scale. Options include:
îš‹ [40], [60] and [80] if the unit is mmHg;
îš‹ [5.0], [7.5] and [10.0] if the unit is % or kPa.
5. Select
to exit the current menu.
For details about displaying the CO
2
waveform, refer to 5.3.3.2Display CO2 Waveform.
9.6 Change Anesthetic Agent
If the anesthetic agent used changes, the AG module is capable of detecting the gas mixture
during the transition period. The time required for anesthetic agent exchange depends upon
the type of anesthesia (low flow or high flow) and the features of the anesthetic agents used
(pharmacokinetics). During the exchange, the anesthesia machine gives no prompt message
and the MAC values displayed may be inaccurate.
The M-type AG module cannot identify anesthetic agent automatically. Therefore, you need
to change the setting of [Agent] to let the agent set consistent with the agent applied.
