Mindray WATO EX-65 Operator's Manual

10-1
10 BIS Monitoring
10.1 Introduction
Bispectral index (BIS) monitoring is for use on adult and pediatric patients within a hospital
or medial facility providing patient care to monitor the state of the brain by data acquisition
of EEG signals.
The BIS, a processed EEG variable, may be used as an aid in monitoring the effects of certain
anesthetic agents. Use of BIS monitoring to help guide anesthetic administration may be
associated with the reduction of the incidence of awareness with recall during general
anesthesia or sedation.
The BISx equipment must be used under the direct supervision of a licensed healthcare
practitioner or by personnel trained in its proper use.
The measurement provides:
1. BIS EEG and BIS Trend waveforms;
2. Measured parameters: BIS, SQI, EMG, SR, SEF and TP.
10.2 Identify the BIS Module
BIS cable connector
BIS setup ke
y
Indicator
Check sensor key

Mindray WATO EX-65 Specifications

General

Type	Anesthesia Machine
Model	WATO EX-65
Brand	Mindray
Tidal Volume Range	20 to 1500 mL
O2 Concentration	21% to 100%
I:E Ratio	4:1 to 1:8
Ventilation Modes	VCV, PCV, SIMV, Manual, Spontaneous
Flow Meter	O2, N2O
Vaporizer	Up to 2 vaporizers
PEEP	0 to 20 cmH2O
Gas Supply	O2, N2O, Air
Monitoring	Airway Pressure, Flow, Volume
O2 Flush	35 to 75 L/min
Respiratory Rate	4 to 100 breaths per minute
Power Supply	100 to 240 VAC, 50/60 Hz
Fresh Gas Flow	0 to 15 L/min
