3-4
4. Physiological alarm area
Displays physiological alarm messages.
5. Apnea alarm off icon area
Displays apnea alarm off icon
when apnea alarm is switched off in
non-mechanical ventilation mode.
6. Alarm silence icon area
Displays alarm silence icon and 120 s countdown time.
7. System time area
Displays system time of the anesthesia machine.
8. Technical alarm area
Displays technical alarm messages. When multiple alarms occur, they are displayed
cyclically.
9. Power supply state icon area
Displays power source or battery icon.The icon
is displayed when the anesthesia
machine is powered by AC power source. The battery icon is displayed when the
anesthesia machine is battery powered to indicate battery capacity. For details, refer
to2.3 Batteries.
10. [Vent Mode] shortcut key Used to select mechanical ventilation mode.
11. [Alarm Setup] shortcut key
Used to change the alarm settings for the anesthetic ventilator, gas modules or BIS
module.
12. [Screens] shortcut key
Used to set user screen.
13. [User Setup] shortcut key
Used to change the settings for TV compensation, O2 monitoring source, gas module,
BIS module, screen, sound etc.
14. [Maintenance] shortcut key
Used to perform leak test, calibrate O2 sensor and flow sensor, view trend graph, trend
table and alarm logbook, and set language, system time, pressure unit, IP address etc.
15. Timer setup shortcut key
Used to start, stop and reset the timer.
16. Parameter setup shortcut keys area
Used to set the parameters related to the selected mechanical ventilation mode. The
arrangement of the shortcut keys in this area varies depending on the selected
mechanical ventilation mode. For details, refer to 4 Operations and Ventilation Setup.
17 System prompt message area
