Mindray WATO EX-65 - Equipment Symbols

1-5
1.2 Equipment Symbols
Attention: Consult
accompanying documents (this
manual)
Dangerous voltage
Alternating current
Fuse
Battery Equipotential
Operating state Autoclavable
Material description
Not autoclavable
Power On
Power Off
Reset
Standby
Alarm silence key MV&TVe alarm key
Normal screen key
O
2
flush button
ACGO On
ACGO Off
Bag position/ manual
ventilation
Mechanical ventilation
Lock
Unlock
Network connector Flow control
USB connector
O
2
sensor connector
Air supply connector
N
2
O supply connector
Upward (Pop-off valve)
Sample gas return port
(to the AGSS)
