Mindray WATO EX-65 - Bag;Mechanical Ventilation Switch; APL (Airway Pressure Limit) Valve; Sodalime Canister

2-6
1. O
2
sensor connector
2. Inspiration connector
3. Expiration connector
4. Inspiratory check valve
5. Expiratory check valve
6. Bellows housing
7. Sample gas return port (to the AGSS)
8. Manual bag port
9. Bag/mechanical ventilation switch
 Select the position to use bag for manual ventilation.
 Select the position to use ventilator for mechanical ventilation.
10. APL (airway pressure limit) valve
Adjusts breathing system pressure limit during manual ventilation. The scale shows
approximate pressures. Above 30 cmH
2
O, you will feel clicks as the v turns. Turn
clockwise to increase.
11. O
2
sensor connector
12. Rotary handle
13. Sodalime canister
The sodalime inside the canister absorbs the CO
2
the patient exhales, which enables
cyclic use of the patient exhaled gas.
