Mindray WATO EX-65 Operator's Manual

8-6
8.3.2.7 Set CO2 Waveform
1. Select the waveform area to access the waveform setup menu.
2. Select [Waveform] and select [CO2].
3. Select [Sweep] and set waveform sweep speed to an appropriate value. The greater the
value is, the faster the waveform sweeps, the wider the waveform is.
4. Select [Scale] and toggle between:
 [40], [60] and [80] if the unit is mmHg;
 [5.0], [7.5] and [10.0] if the unit is % or kPa.
5. Select
to exit the current menu.
For details about displaying the CO2 waveform, refer to 5.3.3.2Display CO2 Waveform.
8.3.3 Measurement Limitations
Measurement accuracy may degrade due to:
 Leakage or internal leakage of the sample gas.
 Mechanical shock
 Cyclic pressure which is greater than 10 kPa (100 cmH2O)
 Other interference source (if available)
8.3.4 Troubleshooting
When the sampling system of the CO2 module works incorrectly, check if the sampling tube
is kinked. If not, remove the sampling tube from the watertrap. Then, if a prompt message
indicating airway malfunction appears on the screen, it means that the watertrap is occluded.
In this case, you must replace the watertrap. If no such prompt message is displayed, it means
that the sampling tube is occluded. Then you must replace the sampling tube.

Mindray WATO EX-65 Specifications

General

Type	Anesthesia Machine
Model	WATO EX-65
Brand	Mindray
Tidal Volume Range	20 to 1500 mL
O2 Concentration	21% to 100%
I:E Ratio	4:1 to 1:8
Ventilation Modes	VCV, PCV, SIMV, Manual, Spontaneous
Flow Meter	O2, N2O
Vaporizer	Up to 2 vaporizers
PEEP	0 to 20 cmH2O
Gas Supply	O2, N2O, Air
Monitoring	Airway Pressure, Flow, Volume
O2 Flush	35 to 75 L/min
Respiratory Rate	4 to 100 breaths per minute
Power Supply	100 to 240 VAC, 50/60 Hz
Fresh Gas Flow	0 to 15 L/min
