Mindray WATO EX-65 - Ventilator Accuracy; Control and Monitoring Accuracy; Alarm Settings

B-9
B.8 Ventilator Accuracy
Control and monitoring accuracy
Volume control
<75 ml: ±15 ml;
≥75 ml: ±20 ml or ±10% of the set value, whichever is greater.
Pressure control
Pinsp: ±3.0 cmH
2
O or ±8% of the set value, whichever is greater.
Plimit: ±4.0 cmH
2
O or ±10% of the set value, whichever is greater.
PEEP control
4 to 30 cmH
2
O: ± 2.0 cmH
2
O, or ±10% of the displayed value,
whichever is greater;
OFF: not defined.
Volume monitoring
<75 ml: ±15 ml;
≥75 ml and <1500 ml: ±20 ml or ±10% of the set value, whichever
is greater;
>1500 ml: not defined.
Pressure monitoring ±2.0 cmH
2
O
PEEP monitoring
accuracy
0 to 30 cmH
2
O: ± 2.0 cmH
2
O, or ±10% of the displayed value,
whichever is greater;
>30 cmH
2
O: not defined.
Alarm settings
Parameter Setting range Remark
High Limit 20 to 100 %
FiO2
Low Limit 18 to（high limit -2）%
The specified high limit
shall always be greater
than the low limit.
High Limit 5 to 1600 mL
TVe
Low Limit 0 to（high limit -5）mL
The specified high limit
shall always be greater
than the low limit.
High Limit 0.2 to 30L
MV
Low Limit 0 to 10L
The specified high limit
shall always be greater
than the low limit.
High Limit 4 to 100 BPM
Rate
Low Limit 2 to（high limit -2）BPM
The specified high limit
shall always be greater
than the low limit.
High Limit 6 to 97 cmH
2
O
Paw
Low Limit 0 to 30 cmH
2
O
/
