11-5
11.4.3 Set AG Alarm Limits
1. Select the [Alarm Setup] shortcut key and then [Gas Module >>].
2. Set [High Limit] and [Low Limit] respectively for each parameter.
3. Select
to exit the current menu.
11.4.4 Set BIS Alarm Limits
1. Select the [Alarm Setup] shortcut key and then [Gas Module >>].
2. Set [High Limit] and [Low Limit] respectively for each parameter.
3. Select
to exit the current menu.
11.5 Set Alarm Level
To set the alarm level for CO2 or AG, select the [Alarm Setup] shortcut key →[Gas Module
>>] → [Alarm Level]. The CO2 or AG alarm level toggles between [High] and [Med].
To set the alarm level for BIS, select the [Alarm Setup] shortcut key →[BIS Module >>]
→[Alarm Level]. The BIS alarm level toggles between [High], [Med] and [Low].
NOTE
z For this anesthesia machine, only alarm levels for the parameters related to CO
2
,
AG, or BIS module can be set. Alarm level for other parameters is factory
configured.
11.6 Set Cardiopulmonary Bypass (CPB) Alarm
In non-mechanical ventilation mode:
1. Select the [Alarm Setup] shortcut key and select [Ventilator >>].
2. Select [CPB] and toggle between [ON] and [OFF].The systems prompts [CPB] when
[CPB] is set to [ON].
3. In mechanical ventilation mode, the system automatically sets [CPB] to [OFF]. Such
setting is not user adjustable.
