3 Calibration
50
3.7.3
Simplified numerical value input based calibration
In the simplified numerical value input based calibration, you should check the following parameter
settings one by one while pressing , and change the settings on an as-needed basis.
Decimal point display position
Unit weight
Measuring weight
mV/V value of zero point
mV/V value of span
1. Hold down to display and flash .
2. Press .
The currently set decimal point display position flashes.
3. Change the decimal point display position by using and on an as-needed basis.
Whenever is pressed, the decimal point display position is cyclically changed from [0],
[0.0], [0.00], and [0.000] to [0.0000], in ascending order. Similarly, whenever is pressed,
the decimal point display position is cyclically changed in descending order.
For setting procedures of decimal point display position, see Section 3.3, "Setting the decimal point display
position".
4. Press .
flashes.
5. Press .
The currently set unit weight flashes.
6. Similar to the case of decimal point display position, change the unit weight on an as-needed
basis. Only 1, 2, 5, or 10 can be set.
When you have set the number of digits in the decimal place, the rightmost figure will be 1, 2, 5,
or 10. Whenever is pressed, the unit weight is cyclically changed from 1, 2, and 5 to 10, in
ascending order. Similarly, whenever is pressed, the unit weight is cyclically changed in
descending order.
7. Press .
flashes.
8. Press .
The currently set measuring weight appears.
9. Change the measuring weight by using and on an as-needed basis.
CAUTION
The measuring weight does not accept [0]. When you select [0] and press ,
flashing appears and then reappears and flashes.
For setting procedures with and , see Section 1.6, "Basic key operation".
To Next Page
