5 Settings Related to Detection
63
4. Using and , change the numerical value to and press .
The number showing the currently set detection operation appears.
Number Detection operation
00 Peak
01 Bottom
02 Peak-bottom
03 Peak-to-peak
04 Minimum
05 Maximum
06 Maximum-minimum difference
07 Inflection point A
08 Inflection point B
09 Inflection point C
10 Inflection point D
11 Average
00 (Peak)
For setting procedures with and , see Section 1.6, "Basic key operation".
5. Using and , set the number showing the detection operation.
6. Press .
7. Press twice to return to Measurement mode.
▼ Setting the reference point [PF-10]
When you have selected [02] (Peak-bottom) as the desired detection operation, you should set the
reference point to P function PF-10. Described below are the reference point setting procedures.
1. Press once to display .
2. Press twice to change the display to .
3. Press .
The P function mode is activated, and the display changes to a two-digit numerical value
prefixed with [PF-].
4. Using and , change the numerical value to and press .
The currently set reference point appears.
0
For setting procedures with and , see Section 1.6, "Basic key operation".
5. Using and , set the reference point.
You can set any value between -99 999 and 99 999, which will be displayed in the load window.
6. Press .
7. Press twice to return to Measurement mode.
Default
Default
