Motorola MC40 - Table 11-2 SE4500-DL Decode Distances; Figure 11-1 SE4500-DL Decode Zone

MC40IntegratorGuide
Figure11-1SE4500–DLDecodeZone
Table11-2SE4500-DLDecodeDistances
TypicalWorkingRanges
SymbolDensity/
BarCodeType
BarCodeContent/Contrast
Note2
NearFar
3.0mil
Code39
80%MRD
2.7in
6.86cm
4.2in
10.67cm
5.0mil
Code39
ABCDEFGH
80%MRD
1.4in
3.56cm
7.3in
18.54cm
5.0mil
PDF417
80%MRD
2.8in
7.11cm
4.5in
11.43cm
6.67mil
PDF417
4Col,20Rows
80%MRD
1.9in
4.83cm
6.9in
17.53cm
7.5mil
Code39
ABCDEF
80%MRD
Note1
9.9in
25.15cm
