11.3MC40ConnectorPin-Outs
Table11-2SE4500-DLDecodeDistances(cont'd.)
TypicalWorkingRanges
SymbolDensity/
BarCodeType
BarCodeContent/Contrast
Note2
NearFar
10mil
PDF417
3Col,17Rows
80%MRD
Note1
9.0in
22.86cm
13mil
UPC-A
012345678905
80%MRD
1.6in
5.08cm
12.0in
30.48cm
15mil
PDF417
80%MRDNote1
11.7in
29.72cm
15mil
DataMatrix
18x18Modules
80%MRD
2.3in
5.84cm
11.2in
28.45cm
20mil
Code39
123
80%MRD
Note1
19.7in
50.04cm
1.NeardistancesareFOVlimited.
2.ContrastismeasuredasMeanReectiveDifference(MRD)at670nm
3.Workingrangespecicationsattemperature=23°C,pitch=18°,roll=0°,skew=0°,
photographicquality,ambientlight~30ft-c,humidity45-70%RH.
4.Distancesmeasuredfromfrontedgeofscanenginechassis.
11.3MC40ConnectorPin-Outs
HeadsetConnector
Figure11-2HeadsetConnector
Pin 1
Pin 3
Pin 2
Table11-3HeadsetConnectorPin-Outs
Pin
Signalname
Description
1
Mic+Microphonepositive
2
Speaker+peakerpositive(32ohm,0.05W,mono)
3GND
Ground
MN000112A01-September2013
11-5
