MC40IntegratorGuide
4PlugtheAClinecordintoanACoutlet.
Figure2-7Setupwith2–wayDCCable
2.3.3FourChargerSetup
ProcedureSteps
1Plugthe4-wayDCCableplugsintothepowerportonthebackoftheeachcharger.
2Plugthe4-wayDCCableconnectorintothepoweroutputofthepowersupply.
3PlugtheAClinecordintothepowersupply.
4PlugtheAClinecordintoanACoutlet.
2-8
MN000112A01-September2013
