Motorola MC40 - Charing Using the Five Slot Charge Only Cradle; Figure 2-16 Remove Insert

MC40IntegratorGuide
2Pullinsertoutofcradle.
Figure2-16RemoveInsert
2.4.5CharingUsingtheFiveSlotChargeOnlyCradle
InserttheMC40intoaslottobegincharging.
TheRightLEDindicatesthestatusofthebatterychargingintheMC40.SeeTable1-1BatteryChargeLEDStatus
forchargingstatusindications.The2680mAhbatterychargesinapproximatelyfourhours.
Chargebatteriesinambienttemperaturesfrom0°Cto40°C(32°Fto104°F)orupto45°C(113°F)asreported
bythebattery.Toviewthebatterytemperature,touch
>Aboutdevice>BatteryInformation.Chargingis
intelligentlycontrolledbytheMC40.Toaccomplishthis,forsmallperiodsoftime,thechargeralternatelyenables
anddisablesbatterychargingtokeepthebatteryatacceptabletemperatures.Thechargerindicateswhenchargingis
disabledduetoabnormaltemperaturesviaitsLED.
