Motorola MC40 - Five Slot Charge Only Cradle; Installing a Cup; Figure 2-10 Five Slot Charge Only Cradle

2.4FiveSlotChargeOnlyCradle
2.4FiveSlotChargeOnlyCradle
TheFiveSlotChargeOnlycradle:
•ProvidespowerforoperatingandchargingtheMC40.
•SimultaneouslychargesuptoveMC40s.
Figure2-10FiveSlotChargeOnlyCradle
2.4.1InstallingaCup
TheFiveSlotChargeOnlyCradleshipswithoutanycradlecupsinstalled.TobaseacceptstheMC40Charging
Cup,BatteryChargerCupandBlankSlotCover.Toinstallthecradlecups:
ProcedureSteps
1Removepowerfromthecradlebasebeforeinstallingcups.
