Motorola MC40 - Table 11-4 Power Connector Pin-Outs; Table 11-5 Micro-B USB Connector Pin-Outs; Figure 11-3 Power Connector; Figure 11-4 Micro-B USB Connector

MC40IntegratorGuide
PowerConnector
Figure11-3PowerConnector
Pin 1 Pin 2
Table11-4PowerConnectorPin-Outs
PinDescription
1
+5VDCinputpower.
2
Ground
USBConnector
Figure11-4micro-BUSBConnector
Pin 5 Pin 1
Table11-5micro-BUSBConnectorPin-Outs
PinDescription
1+5VDC
2
Data-
3
Data+
4
Permitsdistinctionofhostconnectionfromslave
5
Signalground
