2.3.4ChargingwiththeFourSlotBatteryCharger
Figure2-8Setupwith4–wayDCCable
2.3.4ChargingwiththeFourSlotBatteryCharger
Tochargethesparebatteriesinsertthesparebatteryintoasparebatterychargingwell.
AChargeLEDisprovidedforeachbatterychargingwell.SeeTable2-2SpareBatteryChargeLEDStatusfor
chargingstatusindications.The2680mAhbatterychargesinapproximatelyfourhours.
MN000112A01-September2013
2-9
