Motorola MC40 - Four Slot Battery Charger; Figure 2-5 MC40 Battery Charging

MC40IntegratorGuide
Figure2-5MC40BatteryCharging
TheRightLEDindicatesthestatusofthebatterycharging.SeeTable1-1BatteryChargeLEDStatusforcharging
statusindications.The2680mAhbatterychargesinapproximatelyfourhours.
Chargebatteriesinambienttemperaturesfrom0°Cto40°C(32°Fto104°F)orupto45°C(113°F)asreported
bythebattery.Toviewthebatterytemperature,touch>Aboutdevice>BatteryInformation.Chargingis
intelligentlycontrolledbytheMC40.Toaccomplishthis,forsmallperiodsoftime,thechargeralternatelyenables
anddisablesbatterychargingtokeepthebatteryatacceptabletemperatures.Thechargerindicateswhenchargingis
disabledduetoabnormaltemperaturesviaitsLED.
2.3FourSlotBatteryCharger
TheFourSlotBatteryChargerchargesuptofourMC40sparebatteries.
