MC40IntegratorGuide
ProcedureSteps
1InstallaBatteryChargerCup.See2.4.1InstallingaCup,page2-11.
2AlignthemountingslotsonthebottomoftheFourSlotBatteryChargerwiththescrewsonthecup.
3SlidetheFourSlotBatteryChargerdownuntilitsnapsintoplace.
Figure2-13MultiSlotChargeOnlyCradleFourSlotBatteryChargerInstallation
2.4.3PowertoFiveSlotChargeOnlyCradle
UseonepowersupplytoprovidepowertotheChargingBasetopowertheChargingCups.Aseparatepower
supplyisrequiredforeachFourSlotBatteryChargerinstalled.Thepowersupplyisconnecteddirectlytothe
ForSlotBatteryCharger.
2-14
MN000112A01-September2013
