Motorola MC40 - Figure 2-6 Four Slot Battery Charger; Single Charger Setup; Two Charger Setup

2.3.1SingleChargerSetup
2.3.1SingleChargerSetup
ProcedureSteps
1Plugthepowersupplyplugintothepowerportonthebackofthecharger.
2PlugtheAClinecordintothepowersupply.
3PlugtheAClinecordintoanACoutlet.
Figure2-6FourSlotBatteryCharger
2.3.2TwoChargerSetup
ProcedureSteps
1Plugthe2-wayDCCableplugsintothepowerportonthebackoftheeachcharger.
2Plugthepowersupplyplugintothejackofthe2-wayDCCable.
3PlugtheAClinecordintothepowersupply.
MN000112A01-September2013
2-7
