MC40IntegratorGuide
Decoders
Congureswhichbarcodedecodersareenabledordisabled.Forbestperformancedisableallunnecessarydecoders.
TouchDecoders.TheBarcodeinputscreenappears.Acheckinthecheckboxindicatesthatthedecoderis
enabled.Bydefaultthemostcommonlyuseddecodersareenabled(shownbelowwithanasterisk).Thesupported
decodersare:
UPC-A*UPC-E0*EAN-13*
EAN-8*Code128*Code39*
Interleaved2of5GS1DataBar*GS1DataBarLimited
GS1DataBarExpandedDatamatrix*QRCode*
PDF417*CompositeABCompositeC
MicroQRAztec*Maxicode*
MicroPDF
USPostnet
USPlanet
UKPostalJapanesePostalAustralianPostal
CanadianPostalDutchPostal
US4stateFICS
Codabar*
MSI
Code93
Trioptic39Discrete2of5Chinese2of5
Korean3of5Code11
TLC39
Matrix2of5
UPC-E1
Touchtoreturntothepreviousscreen.
DecoderParams
UseDecodeParamstocongureindividualdecoderparameters.
•UPCA
–ReportCheckDigit-Thecheckdigitisthelastcharacterofthesymbolusedtoverifytheintegrityofthedata.
Enablesordisablesthisoption.Acheckinthecheckboxindicatesthattheoptionisenabled(default-enabled).
–Preamble-PreamblecharactersarepartoftheUPCsymbolconsistingofCountryCodeandSystem
Character.Selecttheappropriateoptiontomatchthehostsystem.
TherearethreeoptionsfortransmittingaUPCApreamble:
♦PreambleNone-Transmitnopreamble.
♦PreambleSysChar-TransmitSystemCharacteronly(default).
♦PreambleCountryandSysChar-TransmitSystemCharacterandCountryCode(“0”forUSA).Select
theappropriateoptiontomatchthehostsystem.
•UPCE0
–ReportCheckDigit-Thecheckdigitisthelastcharacterofthesymbolusedtoverifytheintegrityofthe
data.Enablesordisablesthisoption.Acheckinthecheckboxindicatesthattheoptionisenabled(default
-disabled).
–Preamble-PreamblecharactersarepartoftheUPCsymbolconsistingofCountryCodeandSystem
Character.Selecttheappropriateoptiontomatchthehostsystem.
4-10
MN000112A01-September2013
