3-89
Unique Switch 037 — Modem
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Factory use only
6 0 Factory use only
5 0 Factory use only
4 0 The delay before post-
message is transmitted
If retraining occurs due to the low reception signal
level and few delay of the telephone line, it may
overlap the second post-message. In this case,
increase the delay before the post-message is
transmitted.
3 0
0 ms 100 ms 200 ms 300 ms
Switch 4: 0 0 1 1
Switch 3: 0 1 0 1
2 0 Factory use only
1 0 Factory use only
0 1 Factory use only
Unique Switch 038 ~ 039 — Factory use only
To Next Page
