Muratec F-525 User Manual

3-92
Unique Switch 049 — Scanner
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Factory use only
6 0 Factory use only
5 0 Trailing edge document
margin adjustment upon
scanning using FBS
Adjusts the trailing edge
margin when scanning
document by FBS.
Each setting changes by
1 mm.
Switch 5 4 3 2 1 0 Settings
0 0 0 0 0 0 0 mm
0 0 0 0 0 1 1 mm
0 0 0 0 1 0 2 mm
0 0 0 0 1 1 3 mm
0 0 0 1 0 0 4 mm
0 0 0 1 0 1 5 mm
0 0 0 1 1 0 6 mm
0 0 0 1 1 1 7 mm
0 0 1 0 0 0 8 mm
0 0 1 0 0 1 9 mm
0 0 1 0 1 0 10 mm
0 0 1 0 1 1 11 mm
0 0 1 1 0 0 12 mm
0 0 1 1 0 1 13 mm
0 0 1 1 1 0 14 mm
0 0 1 1 1 1 15 mm
0 1 0 0 0 0 16 mm
0 1 0 0 0 1 17 mm
0 1 0 0 1 0 18 mm
0 1 0 0 1 1 19 mm
0 1 0 1 0 0 20 mm
0 1 0 1 0 1 21 mm
0 1 0 1 1 0 22 mm
0 1 0 1 1 1 23 mm
0 1 1 0 0 0 24 mm
0 1 1 0 0 1 25 mm
:
1 1 1 1 1 1 63 mm
4 0
3 0
2 0
1 0
0 0
