145
HELP No. Adjustments and checks Contents and descriptions
H-16 OP1 slitter (stepping motor) OP1 slitter positioning motor (stepping motor) function test
function test Slitter moves to the left (opposite the operation panel) when the
<+> key is pressed.
Slitter moves to the right (toward the operation panel) when the
<-> key is pressed.
H-17 Main motor (stepping motor) Main motor function test
function test Motor runs when the <Start> key is pressed.
Motor stops when the <Stop> key is pressed.
H-18 Score (stepping mode) Score motor function test
function test Motor runs forward when the <+> key is pressed.
Motor runs backward when the <-> key is pressed.
H-19 Cutter (stepping mode) Cutter motor function test
function test Motor runs forward when the <+> key is pressed.
Motor runs backward when the <-> key is pressed.
H-20 Slitter blade drive Slitter drive motor function test
(stepping mode) function test Slitter drive motor (forward) runs when the <+> key is pressed.
Slitter drive motor (backward) runs when the <-> key is pressed.
H-21 LED function test The LEDs shown below flash
COVER, JAM, PAPER, and START on the operation panel
PAPER, FEED, and LED on the paper supply
+KEY:GOTO LEFT
-KEY:GOTO RIGHT
17:MAIN MOTOR CK
+,-KEY:SCORE ON
+,-KEY:CUT ON
+,-KEY:SLIT ON
21:LED CHECK
c HELP Description
Chap.7
