NEC SL1100 Programming Manual

Program 16 : Department Group Setup
16-01 : Department Group Basic Data Setup
Level:
IN
Description
Use Program 16-01 : Department Group Basic Data Setup to set the function mode for each
department group. There are 32 available Department Groups.
Input Data
Department Group Number 1 ~ 32
Item
No.
Item Input Data Description Default Related
Program
01 Department
Name
Maximum 12 charac-
ters
This program is used to assign a
name to the department group.
No Setting 11-07
02 Department Call-
ing Cycle
0 = Normal Routing
(Priority)
1 = Easy - UCD Rout-
ing (Circular)
Use this option to set the call routing
for Department Calling. Routing can
be either circular (cycles to all
phones in group) or priority (cycles
to highest priority extensions first).
0 16-02
03 Department
Routing when
Busy (Auto Step
Call)
0 = Normal (Intercom
caller hears busy tone.)
1 = Circular (Intercom
caller routes to an idle
group member.)
Set this option to set how the sys-
tem routes an Intercom call to a
busy Department Group member.
Intercom callers to the extension
can either hear busy or route to the
first available department number.
This only occurs for calls to the ex-
tension directly, not the department
number assigned in Program 11-07.
0 16-02
04 Hunting Mode 0 = Last extension is
called and hunting is
stopped
1 = Circular
Use this option to set the action tak-
en when a call reaches the last ex-
tension in the Department Group (0
= hunting stopped, 1 = hunting re-
peats with circular routing through
the Department Group).
0
05 Extension Group
All Ring Mode
Operation
0 = Manual (Ring the
extensions one at a
time when the service
code are pressed.)
1 = Automatic (Ring all
extensions.)
Determine whether calls ringing a
Department Group should ring all
extensions in the group simultane-
ously automatically or manually
when using the service code defined
in Program 11-12-09.
When set to (1) Automatic, only
ICM Calls and DID Calls will
ring all the stations in the De-
partment Group.
0 11-16-10
06 STG Withdraw
Mode
0 = Disabled (Call will
camp on to the group.)
1 = Automatic (Call fol-
lows PRG 22-11-11.)
0
07 Call Recall Re-
striction for STG
0 = Disabled (Call will
recall.)
1 = Enabled (Call will
not recall.)
Determine whether or not an unan-
swered call transferred to a Depart-
ment Group should recall the exten-
sion from which it was transferred.
0
ISSUE 6.0 SL1100
Programming Manual 2-163
Program
16
