NEC SL1100 Programming Manual

Program 84 : Hardware Setup for VoIPDB
84-16 : VoIPDB Limiter Control Gain Setup
Level:
IN
Description
Use Program 84-16 : VoIPDB Limiter Control Gain Setup to set the Limiter Control Gain
configuration of VoIPDB.
Input Data
Item
No.
Item Input Data Description Default
01 RX Limiter Control
Gain
0 ~ 30 (- 15 dBm ~ + 15
dBm)
0 = - 15 dBm
1 = - 14 dBm
:
15 = 0 dBm
:
29 = 14 dBm
30 = 15 dBm
Gain setting to control limiter in the direc-
tion of IP PCM.
This option adds gain to the voice input
from the LAN and removes it from the
voice output to highway.
15 (0 dBm)
02 TX Limiter Control
Gain
0 ~ 30 (- 15 dBm ~ + 15
dBm)
0 = - 15 dBm
1 = - 14 dBm
:
15 = 0 dBm
:
29 = 14 dBm
30 = 15 dBm
Gain setting to control limiter in the direc-
tion of PCM IP.
This option adds the gain to the voice input
from highway and removes it from the
voice output to the LAN.
15 (0 dBm)
03 RX Limiter Control
Gain (COIU)
0 ~ 30 (- 15 dBm ~ + 15
dBm)
0 = - 15 dBm
1 = - 14 dBm
:
15 = 0 dBm
:
29 = 14 dBm
30 = 15 dBm
This option controls the limiter gain for a
COIU call in the IP to PCM direction.
15 (0 dBm)
04 TX Limiter Control
Gain (COIU)
0 ~ 30 (- 15 dBm ~ + 15
dBm)
0 = - 15 dBm
1 = - 14 dBm
:
15 = 0 dBm
:
29 = 14 dBm
30 = 15 dBm
This option controls the limiter gain for a
COIU call in the PCM to IP direction.
15 (0 dBm)
Conditions
None
ISSUE 6.0
SL1100
Programming Manual 2-507
Program
84
