NEC SL1100 - IP Routing Table Setup

Program 10 : System Configuration Setup
10-45 : IP Routing Table Setup
Level:
SA
Description
Use Program 10-45 : IP Routing Table Setup to set up the IP Routing Table.
Input Data
Routing Table Number 001 ~ 100
Item
No.
Item Input Data Default
01 Network Address 0.0.0.0 ~ 126.255.255.254
128.0.0.0 ~ 191.255.255.254
192.0.0.0 ~ 223.255.255.254
0.0.0.0
02 Subnet Mask 128.0.0.0 | 192.0.0.0 | 224.0.0.0 | 240.0.0.0 |
248.0.0.0 | 252.0.0.0 | 254.0.0.0 | 255.0.0.0 |
255.128.0.0 | 255.192.0.0 | 255.224.0.0 |
255.240.0.0 | 255.248.0.0 | 255.252.0.0 |
255.254.0.0 | 255.255.0.0 | 255.255.128.0 |
255.255.192.0 | 255.255.224.0 | 255.255.240.0 |
255.255.248.0 | 255.255.252.0 | 255.255.254.0 |
255.255.255.0 | 255.255.255.128 |
255.255.255.192 | 255.255.255.224 |
255.255.255.240 | 255.255.255.248 |
255.255.255.252 | 255.255.255.254 |
255.255.255.255 |
0.0.0.0
03 Default Gateway 0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
0.0.0.0
Conditions
None
Feature Cross Reference
None
