CIBANO 500 PTM User Manual
106 OMICRON
The imported CSV files must comply with a special format in which the first line is reserved for a comment
and the second line specifies the units “degree” and “mm” separated by a semicolon (“;”). All following
lines consist of one value pair per line that specifies the transducer movement in degrees and the
converted movement in millimeters separated by a semicolon. The following example shows the general
CSV format structure.
To add a conversion table:
1. Click the Add button .
2. In the Open dialog box, browse to the conversion table you want to add.
Note: To rename a conversion table, click the conversion table, and then edit the conversion table name.
To delete a conversion table, click the Remove button next to the conversion table.
15.2 Bushing data
For the data of the circuit breaker’s bushings, see 16 "Spare bushing data" on page 116.
comment; THIS IS AN EXAMPLE COMMENT
degree;mm
-10.00;-9.00
-9.90;-8.91
...
119.80;241.14
119.90;241.04
